1" x 1/2" NPT 304 Stainless Steel Reducing Coupling Female Class 150
1" x 1/2" NPT 304 Stainless Steel Reducing Coupling Female Class 150
1" x 1/2" 304 Stainless Steel Reducing Coupling Female NPT x Female NPT Class 150
This 304 stainless steel reducing coupling is designed to connect two male threaded NPT pipes of different sizes. It reduces a 1" female NPT connection down to a 1/2" female NPT connection, making it useful for adapting piping systems where a smaller branch or component needs to be connected to a larger line.
Constructed from 304 stainless steel, this fitting offers excellent corrosion resistance and durability for industrial, commercial, compressed air, water, and other compatible piping applications.
The fitting has female NPT threads on both ends and is manufactured with standard tapered NPT pipe threads.
Specifications
- Fitting Type: Reducing Coupling
- Size: 1" x 1/2" NPT
- Connections: Female NPT x Female NPT
- Material: 304 Stainless Steel
- Pressure Class: Class 150
- Thread Type: NPT
- Large Thread: 1"-11½ NPT
- Small Thread: 1/2"-14 NPT
- Configuration: Female x Female
- Country of Manufacture: Vietnam
Thread Size & Diameter Information
For customers who aren't familiar with nominal pipe thread sizing:
- 1" NPT: 1" is the nominal pipe size. The actual outside diameter of a standard 1" male NPT thread is approximately 1.25".
- 1/2" NPT: 1/2" is the nominal pipe size. The actual outside diameter of a standard 1/2" male NPT thread is approximately 0.75".
- 1" NPT: 11½ threads per inch
- 1/2" NPT: 14 threads per inch
Important: NPT pipe sizes are nominal sizes and do not correspond directly to the actual outside diameter of the threads. The measurements above are useful when identifying or matching threaded components.
Features & Benefits
- 304 stainless steel construction for excellent corrosion resistance
- Female NPT x Female NPT configuration
- Reduces a 1" NPT connection to 1/2" NPT
- Class 150 pressure class
- Standard tapered NPT threads
- Compact design for connecting different-size threaded components
- Suitable for many compressed air, water, oil, and general industrial piping applications when compatible with the application
- Ideal for industrial, commercial, maintenance, and repair applications
Please verify thread size, connection type, material compatibility, temperature, and pressure requirements for your specific application before installation.
Made in Vietnam.
You will Receive
1× 1" x 1/2" 304 Stainless Steel Reducing Coupling Female NPT x Female NPT Class 150
