Puma TK-5080V 80 Gallon 5HP 2-Stage Vertical Air Compressor – 1 Phase, 220-240V

The Puma TK-5080V is a heavy-duty, industrial-grade air compressor engineered for performance, reliability, and longevity. With an 80-gallon vertical tank, a powerful 5HP motor, and a 2-stage cast iron pump, this compressor is built to handle demanding shop environments with ease.

Key Features:

  • 5HP Industrial-Grade Motor: Runs at 1750 RPM and drives a compressor pump operating at 970 RPM. The slower pump speed ensures cooler operation, quieter performance, and a longer service life—unlike many competitors with pump speeds of 1400–1500+ RPM.

  • 3-Cylinder All Cast Iron Pump: Unique separated cylinder design allows for better airflow around each cylinder, enhancing cooling and durability.

  • 2-Stage Compression: Delivers up to 175 PSI, with a displacement of 21 CFM and 18.3 CFM at 90 PSI—ideal for powering a wide range of air tools and equipment.

  • Magnetic Starter Included: Pre-installed and ready for wiring to streamline installation.

  • 1/2" Ball Valve Outlet: Standard connection for easy integration into your air system.

  • 80-Gallon Vertical Tank: Compact footprint with a bottom-mounted manual tank drain. (Optional electronic drain available for high-use environments.)

Specifications:

  • Motor: 5HP, 1 Phase, 220V-240 Volt, 23 Amps (3 Phase available upon request)

  • Pump RPM: 970 RPM

  • Motor RPM: 1750 RPM

  • Max Pressure: 175 PSI

  • CFM: 21 displacement, 18.3 at 90 PSI

  • Dimensions: 71.5” Tall x 37.5” Wide x 24.5” Deep

  • Weight: 586 Lbs

  • Mounting: Must be installed on vibration dampening pads if removed from pallet

  • Warranty: 1-Year Manufacturer Warranty

Puma compressors are built to perform under pressure. With cooler operation, smooth performance, and rugged construction, the TK-5080V is a reliable solution for any shop or industrial workspace.

Need help with installation, 3-phase options, or drain upgrades? Reach out to our team—we’re here to assist.
